Minigraver 1800 kg, 100 cm huren

Deze graafmachine wordt veelal ingezet voor grondwerkzaamheden rondom huizen of wegen.

Technical specifications: 301.8C Production year model/type 2005-2006 Engine: Mitsubishi Cil/Turbo/intercooler 3 Engine model: L3E Capacity in Kw/pk/Rpm: 13,5/18,4/2400 Maximum torque: Nm/rpm: x Displacement (cm³) 952 Fuel: Diesel Hydrauliek system: Capacity hydraulic tank: (liter) 24 Capacity hydraulic system: (Liter) 37 Pump flow capacity: (ltr/min) 2 x 20 Auxilary flow capacity: (Liter) (option) Maximum working pressure: (bar) 206 Dimensions & weight: Arm (std) Operating weight cab: (Kg) 1785 Operating weight canopy: (Kg) 1680 Length transport: (mm) 3695 Height cab: (mm) 2190 Height canopy: (mm) Height transport: (mm) 2190 Body width: (mm) Width over tracks: (mm) 980-1340 Width dozer blade: (mm) 980-1340 Lenght tracks on the ground: (mm) 1575 Track width: (mm) 230 Ground pressure: (kg/cm²) Gradebility: (%/°) 30° Fuel tank: (Liter) 22 Operating information: Arm (std) long arm Max. reach at ground level: (mm) 3610 3800 Max. loading height: (mm) 2360 2480 Max. digging depth: (mm) 2080 2320 Max. cutting height: (mm) 3350 3460 Maximum travel speed low/high: (Km/h) 2,0-4,5
